WCED WFD110B-030 Bi-Directional Type A 30mA B Curve 10A AFDD
£66.15
A 10A-rated protection device integrating a 30mA Type A RCBO with advanced arc fault detection, ensuring reliable safety for residential and commercial electrical installations.
Available on back-order
| 3 | – | £63.50 | £2.65 | £66.15 |
| 5 | – | £61.52 | £4.63 | £66.15 |
Description
Type A Single Module 10A B Curve 30mA Arc Fault Detection Device
WCED WFD110B-030
The WCED WFD110B-030 AFDD is a high-performance 10A-rated circuit protection device that combines a 30mA Type A RCBO with an integrated Arc Fault Detection Device (AFDD). It continuously monitors for hazardous arc faults, disconnecting power upon detection to prevent potential fires. Its bi-directional design and switched neutral feature provide enhanced safety for residential and commercial applications.
Key Features:
- 10A Rated Current
- Integrated 30mA Type A RCBO + AFDD
- Advanced Arc Fault Detection
- Switched Live & Neutral Isolation
- Overvoltage Protection at 275V ±5%
- Self-Testing Mechanism
- Compact Space-Saving Design
Why Choose This Product?
Designed for enhanced safety, the WFD110B-030 actively monitors electrical circuits, ensuring prompt disconnection when faults occur. Its combination of arc fault protection and residual current detection makes it a must-have for environments requiring increased fire prevention.
Where Is It Required? (BS 7671:2018)
BS 7671 advises the use of AFDDs in student accommodations, hotels, and rental properties to protect against electrical fires caused by arc faults and damaged wiring.
Additional information
| Brand | WCED |
|---|---|
| Product | AFDD, AFDD with RCBO |
| Voltage | 230V |
| Fault Current | 6kA |
| RCD Trip Current Rating (mA) | 30mA |
| RCBO / RCD Type | Type A |
| Curve | B |
| Current Rating (A) | 10 |
