Niglon RCBO1-20/30SAX2 20A Curve B 30mA Bi-Directional A Type RCBO

Description

20A Curve B 30mA Bi-Directional A Type RCBO – Compact RCBO, Switched Line & Neutral, 6kA

Smart Protection for Small Power and PV Circuits – Niglon RCBO1-20/30SAX2 20A RCBO

Niglon RCBO1-20/30SAX2

The Niglon RCBO1-20/30SAX2 20A RCBO delivers compact and dependable circuit protection for radial socket outlets, small heating loads, and PV-ready boards. Its bi-directional operation means it protects circuits from earth leakage and overcurrent faults, whether power flows in the normal or reverse direction.

This functionality is especially important in solar PV installations, where energy exported from an inverter may travel back through the protective device. Unlike standard RCBOs, this model continues to operate and trip correctly regardless of current flow—ensuring full compliance and peace of mind.

With 30mA Type A RCD sensitivity, Curve B tripping, and switched line and neutral, it supports safe, efficient, and space-conscious installations in any 18th Edition board.

Key Features of the Niglon RCBO1-20/30SAX2 20A RCBO

• 20A Current Rating – Ideal for socket circuits and small fixed loads
• Curve B Tripping – Trips at 3–5 times rated current
• 30mA Type A RCD – Detects both AC and pulsating DC earth leakage
• Bi-Directional Protection – Required for PV installations with reverse current
• Switched Line & Neutral – Improves isolation and user safety
• Breaking Capacity: 6kA – Complies with residential installation standards
• Voltage: 230V AC, 50Hz
• Cable Capacity: 25mm² (line in), 10mm² (line/neutral out)
• Module Width: 18mm – Compact RCBO suitable for tight spaces
• Standards: BS EN 61009-1, BS7671:2018

Applications

• 20A radial socket circuits
• Kitchen appliance circuits
• PV solar installations requiring bi-directional fault detection
• New builds and 18th Edition consumer unit upgrades

Why Choose the Niglon RCBO1-20/30SAX2 20A RCBO?

Choose the Niglon RCBO1-20/30SAX2 20A RCBO for dependable protection in both conventional and renewable energy setups. Its compact footprint, dual-pole isolation, and reverse current detection make it future-ready and ideal for PV systems.

Summary

The Niglon RCBO1-20/30SAX2 20A RCBO is a compact, Curve B, Type A device with 30mA RCD protection. Its bi-directional function ensures compatibility with solar PV circuits and 18th Edition consumer units.
